Blue colour sheath.Finish the order code with “N” for the black sheat.
Particularly suitable for supply and control circuits, lifting and handling equipment.
Comply with: CEI 20-22 II (flame resistant).
Rated operating voltage: 400V.
Max short circuit temparature: 160°C.
Insulation class: 2/3.
Rated insulation voltage: Uo/U 450/750V.
Operating temperature: -5°C + 70°C.
Internal conductors with flexible PVC sheath progressively numbered, plus earth conductor (yellow/green).
On request the cables can be supplied with a tinned red copper shield heat resistant up to 105 ° C (minimum requirement is 2000 m).
Available a wide range of flat cables, refer to the catalog for codes.
PENDANT CABLES
Details
Blue colour sheath. Finalize the code with “N” for the black colour.
Made for heavy duty applications, in particular for pendant push button stations and moving electromechanical components.The two strain relief ropes avoid any stress on the cable; they are embedded, diametrically opposed to PVC sheath.
Comply with: CEI 20-22 II (flame resistant).
Rated operating voltage: 230V.
Max short circuit temparature: 160°C.
Ø2mm steel strain relief ropes.
Insulation class: 2/3.
Rated insulation voltage: Uo/U 300/500V.
Operating temperature: -5°C +70°C.
Breaking point: 60kg/mm².
Internal conductors with flexible PVC scheath progressively numbered, plus earth conductor (yellow/green).
Available a wide range of round cables, refer to the catalog for codes.
